MARTIN AUDIO F12 Speaker

The Martin Audio F12, typically part of the “Blackline” series (e.g., Blackline F12+), is a highly regarded compact, full-range, two-way passive loudspeaker system. It’s engineered to provide efficient and reliable sound reinforcement for a wide array of applications, from live music venues and DJ sets to installed sound systems and stage monitoring.

Key Features and Performance:

Drivers:
Low Frequency (LF): Features a 12-inch (300mm) LF driver with a 2.5-inch (63.5mm) voice coil. This driver is designed for efficient bass reproduction and is often constructed with a water-resistant cone and an aluminum demodulating ring to reduce distortion and improve midrange performance at high output levels.

High Frequency (HF): Equipped with a 1-inch (25mm) exit HF compression driver, typically with a lightweight Kapton diaphragm for extended high-frequency response and clarity.

Horn and Dispersion: The HF driver is mounted on a user-rotatable 80° horizontal by 50° vertical constant directivity horn. This rotatable design allows for optimal coverage patterns whether the speaker is used in a vertical orientation for FOH (Front of House) or horizontally as a floor monitor, ensuring consistent sound distribution.

Frequency Response and Power Handling: The F12 typically exhibits a frequency response from 65 Hz to 18 kHz (±3 dB) with a usable low-end extension down to 55 Hz (-10dB). It is rated for 300 W AES (continuous) power handling and 1200 W peak power, making it capable of delivering substantial output for its size.

Crossover: An internal passive crossover network, often set around 2.2 kHz, is employed to seamlessly integrate the LF and HF drivers, ensuring coherent sound reproduction.

Enclosure and Versatility:

Constructed from multi-laminate birch ply, the cabinet is designed for acoustic integrity and durability.

Its multi-angled design makes it well-suited for use as a highly intelligible floor monitor.

Multiple M8 threaded inserts (typically ten) and four M8 bracket inserts provide versatile mounting options for flying, wall mounting, or bracket mounting.

An integral top hat fitting allows for standard pole mounting on speaker stands, and this fitting can also serve as a pole socket when used in conjunction with a subwoofer.

Ergonomic pocket handles are included for easier transport and positioning.

Connectivity and Impedance: The F12 is a passive 8-ohm nominal impedance speaker, fitted with two Neutrik NL4 (Speakon) connectors for reliable and secure connections.

Sensitivity and SPL: The speaker boasts a high sensitivity rating, typically 97 dB (1W @ 1m), allowing it to achieve impressive sound pressure levels (SPL) with moderate amplifier power. It can typically reach 122 dB continuous and 128 dB peak SPL.

Applications: The Martin Audio F12 is an excellent choice for:

Live club performances and small to medium-sized venues.

Stage monitoring due to its angled cabinet and clarity.

Fixed installations in churches, AV presentations, and corporate events.

DJ setups where a compact yet powerful speaker is needed.

Dimensions and Weight: It typically measures around 398 mm (W)×571 mm (H)×365 mm (D) (15.6 ins×22.5 ins×14.3 ins) and weighs approximately 21 kg (46 lbs).

The Martin Audio F12 is recognized for its blend of compact design, robust build quality, and impressive sonic performance, making it a trusted choice for professionals seeking efficient and reliable sound reinforcement.
